Consolidated Commodore

History

A pioneer of the long-haul passenger aircraft industry, the Commodore "Clipper" grew out of a Navy design competition in the 1920s to create an aircraft capable of nonstop flights between the mainland of the United States and Panama, Alaska, and the Hawaiian Islands. In response to these requirements, Consolidated produced the prototype XPY-1 Admiral, designed by Isaac M. Laddon, in January 1929. Consolidated lost out on the contract to produce the airplanes for the navy to the Glenn L. Martin Company. Martin produced one prototype XP2M and nine production P3Ms. The aircraft represented a marked change from earlier patrol boat designs such as the Curtiss NC.

In response to losing the Navy contract, Consolidated offered a passenger-carrying version of the XPY-1, which became known as the Commodore. A parasol wing monoplane with all-metal hull, it could accommodate 32 passengers and a crew of three. The full complement of passengers, located in three cabins, could be carried only on relatively short route segments. For a 1000-mile flight, the boat probably could accommodate no more than 14 people including the crew. Wing and tail construction consisted of a metal frame structure covered with fabric, except for metal-covered leading edges. The Commodore had significant changes from the XPY-1. These included more powerful engines, fuselage shape and structural improvements.

Operational service

With a first flight in 1929, a total of 14 Commodore boats were built. Starting February 18, 1930, Commodores were flown by the New York, Rio, Buenos Aires Line from the United States to South America where routes extended as far south as Buenos Aires, a distance of 9000 miles from Miami. One testimony to the Commodore in Pan Am service was made by a Pan Am pilot, Marius Lodeesen who wrote " . . . the good old Consolidated Commodore was the most reliable, trusty air craft of the Pan American fleet during the early 1930s. . . . She was hoisted aloft by two engines. They must have been Pratt and Whitneys because they never gave any trouble. . . Waterlooping the Commodore was impossible. Making a bad landing in her was hard work. She was the loveliest boat I ever flew."

As the 1930s progressed the Commodores were gradually superseded by more efficient aircraft such as the Sikorsky S-42, Martin 130, and Boeing 314. A number of Commodores went on to serve with other operators.

The plane, in both its military and civilian configurations, may be considered a first step in the United States toward highly efficient monoplane-type patrol and transport flying boats later in the 1930s and 1940s, such as the famous Consolidated PBY Catalina of World War II.

Surviving aircraft

The only known Model 16 Commodore remaining has been located in a northern Canadian lake. There is currently an ongoing project to raise and restore this airframe for display at the San Diego Air & Space Museum.
