Savoia-Marchetti S.73

Design and development

The aircraft was developed in only four months, thanks to the use of the S.55 wing, combined with a much more conventional fuselage. Developed in parallel with a bomber version (the SM.81 Pipistrello) the prototype S.73 first flew on 4 June 1934 from Cameri, with Adriano Bacula as test pilot.

The prototype had a four-blade wooden propeller on the central engine, and two-blade wooden propellers on each wing engine. Later all aircraft were fitted with three-blade metal propellers.

The S.73 was a mixed-construction (a skeleton of steel covered by wood and fabric for the fuselage, wood for the three-spar wing) monoplane with a braced tailplane and fixed undercarriage. There were two generators, one in each side of the fuselage; the batteries were 24 V and were rated at 90 A.

The pilot and co-pilot were seated side-by-side in an enclosed cockpit, with a compartment for a radio operator and a mechanic. A passenger compartment could house 18 passengers in two rows.

It had eight metallic fuel tanks, all in the wings, with a total capacity of 3,950 L (1,040 US gal; 870 imp gal). The prototype had French Gnome-Rhône 9Kfr Mistral engines, but further aircraft had 522 kW (700 hp) Piaggio Stella P.X, 574 kW (770 hp) Wright R-1820, 544 kW (730 hp) Walter Pegasus III MR2V, Alfa Romeo 125 or Alfa Romeo 126, driving ground adjustable, three-bladed, aluminium-steel propellers.

It could be used from small airports, had reliable handling and was not too costly. With the 574 kW (770 hp)Wright R-1820 engine the S.73 had cruise/max speeds of 270 / 340 km/h (150 / 180 kn; 170 / 210 mph), 1,000 km (620 mi) range, and 6,300 m (20,700 ft) ceiling. With the 544 kW (730 hp) AR.126 the S.73 had a maximum speed of 345 km/h (186 kn; 214 mph), 1,000 km (620 mi) range, and 7,000 m (23,000 ft) ceiling. The SABCA license-produced aircraft had 671 kW (900 hp) Gnome-Rhône 14K Mistral Major engines for a total of 2,013 kW (2,699 hp), comparable to the last models of S.79s or the CANT Z.1018.

The S.73 had an unremarkable flight test programme with few modifications recommended by the Regia Aeronautica. It was easy to fly, rugged, and easy to operate on the ground, including the ability to fly from short airfields in treacherous terrain, in spite of being under-powered and the lack of leading edge slats. Its mixed construction and fixed landing gear were its main shortcomings, when contemporary aircraft in the US and Germany were of all-metal construction with retractable undercarriages. Some of these had better performance, but the S.73 remained competitive for some years.

Operational history

The first operator of the S.73 was the Belgian airline SABENA, which purchased five Gnome-Rhône 9Kfr Mistral Major-powered S.73s from Savoia-Marchetti in 1935, introducing them on European routes in the summer of 1935. Two of these aircraft were lost in accidents in 1935. Seven more S.73s, powered by Gnome-Rhône 14K Mistral Major engines, were built for SABENA under license by SABCA in 1936–1937, which allowed the S.73 to replace the Fokker F.VII on the service from Belgium to the Congo. This service took four days (with no overnight flying) with a flight time of 44 hours.

The second operator of the S.73 was the Italian airline Ala Littoria, which received at least 21 examples, powered by a variety of engines, including the Piaggio Stella X, the Wright R-1820 and the Alfa Romeo 126 RC.10. They were used on services within Europe and to Italy's African empire. In December 1935, an S.73 was used for a journey from Italy to Asmara, delivering over 200,000 letters, with 6,600 km (4,100 mi) traveled in four days, followed by the return trip to Rome on 6 January 1936. A commercial line was established covering a 6,100 km (3,790 mi) journey. Other users included Avio Linee Italiane (powered by Alfa Romeo 126) and Československé Státní Aerolinie (powered by Walter Pegasus).

At the outbreak of World War II the S.73 was already obsolete, but some of the aircraft were pressed into service with the Regia Aeronautica for operations in Abyssinia and Spain.

Nine S.73s were present in Eastern Africa and used as military transports. Owing to the poor military situation, with British Commonwealth forces on the brink of capturing Addis Ababa, the Duke of Aosta, the Viceroy of Italian East Africa, ordered the remaining three S.73s to be evacuated. After several days of preparation, they took off from Addis Ababa on 3 April 1941 with 36 men on board, planning to fly to Kufra in Libya, 2,500 km (1,600 mi) away, requiring additional fuel tanks in the fuselage. All three aircraft force-landed in the desert, but refuelled at Jeddah, before resuming their journey.

After several days of difficulties, including sand storms that clogged up the air filters, they took off again. Initially, it was planned to make another landing in Beirut but in the meantime Erwin Rommel had conquered Benghazi, so this was the final destination of the three aircraft.
