Boeing 717

Development

Background

Douglas Aircraft launched the DC-9, a short-range companion to its larger four-engine DC-8, in 1963. The DC-9 was an all-new design, using two rear fuselage-mounted Pratt & Whitney JT8D turbofan engines; a small, efficient wing; and a T-tail. The DC-9's maiden flight was in 1965 and entered airline service later that year. When production ended in 1982, a total of 976 DC-9s had been produced.

The McDonnell Douglas MD-80 series, the second generation of the DC-9, began airline service in 1980. It was a lengthened DC-9-50 with a higher maximum take-off weight (MTOW) and higher fuel capacity, as well as next-generation Pratt and Whitney JT8D-200 series engines and an improved wing design. 1,191 MD-80s were delivered from 1980 to 1999.

The McDonnell Douglas MD-90 was developed from the MD-80 series. It was launched in 1989 and first flew in 1993. The MD-90 was longer and featured a glass cockpit (electronic instrumentation) and more powerful, quieter, fuel-efficient IAE V2525-D5 engines, with the option of upgrading to an IAE V2528 engine. A total of 116 MD-90 airliners were delivered.

MD-95

The MD-95 traces its history back to 1983 when McDonnell Douglas outlined a study named the DC-9-90. During the early 1980s, as production of the DC-9 family moved away from the smaller Series 30 towards the larger Super 80 (later redesignated MD-80) variants, McDonnell Douglas proposed a smaller version of the DC-9 to fill the gap left by the DC-9-30. Dubbed the DC-9-90, it was revealed in February 1983 and was to be some 25 ft 4 in (7.72 m) shorter than the DC-9-81, giving it an overall length of 122 ft 6 in (37.34 m). The aircraft was proposed with a 17,000 lbf (76 kN) thrust version of the JT8D-200 series engine, although the CFM International CFM56-3 was also considered. Seating up to 117 passengers, the DC-9-90 was to be equipped with the DC-9's wing with 2 ft (0.61 m) tip extensions, rather than the more heavily modified increased area of the MD-80. The aircraft had a design range of 1,430 nmi (2,648 km; 1,646 mi), with an option to increase to 2,060 nmi (3,815 km; 2,371 mi), and a gross weight of 112,000 lb (51,000 kg).

The DC-9-90 was designed to meet the needs of the newly deregulated American airline industry. However, its development was postponed by the recession of the early 1980s. When McDonnell Douglas did develop a smaller version of the MD-80, it simply shrunk the aircraft to create the MD-87, rather than offer a lower thrust, lighter aircraft that was more comparable to the DC-9-30. With its relatively high MTOW and powerful engines, the MD-87 essentially became a special mission aircraft and could not compete with the all new 100-seaters then being developed. Although an excellent aircraft for specialized roles, the MD-87 often was not sold on its own. Relying on its commonality factor, sales were generally limited to existing MD-80 operators.

In 1991, McDonnell Douglas revealed that it was again considering developing a specialized 100-seat version of the MD-80, initially named the MD-87-105 (105 seats). It was to be some 8 ft (2.4 m) shorter than the MD-87, powered with engines in the 16,000–17,000 lbf (71–76 kN) thrust class. McDonnell Douglas, Pratt & Whitney, and the China National Aero-Technology Import Export Agency signed a memorandum of understanding to develop a 105-seat version of the MD-80. At the 1991 Paris Airshow, McDonnell Douglas announced the development of a 105-seat aircraft, designated MD-95. The new name was selected to reflect the anticipated year deliveries would begin. McDonnell Douglas first offered the MD-95 for sale in 1994.

In early 1994, the MD-95 re-emerged as similar to the DC-9-30, its specified weight, dimensions, and fuel capacity being almost identical. Major changes included a fuselage "shrink" back to 119 ft 4 in (36.37 m) length (same as the DC-9-30), and the reversion to the original DC-9 wingspan of 93 ft 5 in (28.47 m). At this time, McDonnell Douglas said that it expected the MD-95 to become a family of aircraft with the capability of increased range and seating capacity. The MD-95 was developed to satisfy the market need to replace early DC-9s, then approaching 30 years old. The MD-95 was a complete overhaul, going back to the original DC-9-30 design and applying new engines, cockpit and other more modern systems.

In March 1995, longtime McDonnell Douglas customer Scandinavian Airlines System (SAS) chose the Boeing 737-600 for its 100-seater over the MD-95. In October 1995, U.S. new entrant and low-cost carrier ValuJet signed an order for 50 MD-95s, plus 50 options. McDonnell Douglas president Harry Stonecipher felt that launching MD-95 production on the basis of this single order held little risk, stating that further orders would "take a while longer". The ValuJet order was the only order received for some two years.

Engines

As first proposed, the MD-95 was to be powered by a 16,500 lbf (73 kN) thrust derivative of the JT8D-200 series with the Rolls-Royce Tay 670 also considered as an alternative.
